Product Description
1)Suitable for:
Containers, tankers, ferries, General cargo ships, passage ships, Dredgers and any other vessels that need more steering torque.
(2)Main Tech:
Max working torque: 15 KN.M — 250 KN.M
Max. mech. rudder angle: ± 45 degree
Time of rudder movement: ≤28 S
Rudder stock Diameter: 300mm — 900 mm
Working pressure: 13 Mpa — 20 Mpa
Design pressure: 16 Mpa — 24 Mpa
(3)Scope of delivery:
Marine steering gear with hydraulic cylinders
Electro-Hydraulic power station with oil pumps
Oil tanks
Start motors
On requests, the full range of parts will be delivered.
(kn.m)
Nominal Torque Turning
Angle
(°） （s)
Turning time (Mpa)
Max working oil pressure Gear pump/motor (mm)
rudder tiller radius (Mm)
Diameter
of radius
Type No Output
(kw)
10 ±35 ≤28/20 6.5 CBN-316 2 1.1 240 75-130
16 ±35 ≤28/20 10.2 CBN-316 2 1.1 240 75-130
20 ±35 ≤28/20 12 CBN-320 2 2.2 240 75-130
25 ±35 ≤28/20 10.9 CBN-320 2 2.2 290 75-150
30 ±35 ≤28/20 9.8 CBN-320 2 3 290 75-150
40 ±35 ≤28/20 10.3 CBN-420 2 3 360 1160
50 ±35 ≤28/20 12.5 CBN-420 2 4 480 170
63 ±35 ≤28/20 8.4 CBN-420 2 4 480 175
