| Model NO.: | Tnc-g10 |
|---|
| Customization: | Available Customized Request |
|---|
SURFACE GRINDER CONTROLLER Tiny Controls’ surface grinder controller (SGC) is a new concept designed especially for grinding operations. It is a versatile and economical solution designed to automate the repetitive grinding tasks. It features automated longitudinal and cross feed. Specifications and Features: 1. A 20x4 alphanumeric LCD to display status and settings. 2. Easy to understand menus and smooth navigation. 3. 16 bit controller with 32 bit math for precise indexing. 4. Locomotion: a. Longitudinal (X): Automatic setting. b. Cross feed (Y): Set manually 5. Maximum Pulse rate: 40 KHz. 6. Control: 3 Automatic modes select. a.Feed at both sides. b.Feed at one end only. c.No feed. 7. Speed control by potentiometer. 8. Emergency stop. 9. Inputs: 3 NPN Proxy (X limit, Y limit and Emergency input) + 1 On-Off switch for start- stop. 10. Outputs: 4 for motor1 and motor2 (STEP and DIR) + two 12 V outputs (for NPN proximity type sensor) + 5 V (for POT connections). 11. Operating interface: User friendly keys. 13. Panel mount. Visit to http://www.tinycontrols.com/ for more details.
