Product Description

M-310 Visual Fault Locator is used for the measurement in single-mode or multi-mode fibers. It features a rugged design, an universal connector and an accurate measurement. The M-310 visual fault locator easily identifies the cutting, micro-bending of the optic fiber, passes through the jacket fiber and performs an end-to-end fiber identification. Its measurement range is up to 5km. It is an ideal tool for the examination of all kinds of patch cords and ribbon or bunched pigtails in the installation and maintenance of fiber optic networks. FeaturesDetects breaks, micro-bends even through jacketed fibersEnd-to-end visual fiber identificationLocates faults up to 5km along the fiber.Mechanical fusion splice optimizationCompact size and light weight, suitable for field testing ApplicationsMaintenance in TelecomMaintenance CATVTest Lab of optical fibersOther Fiber Optic Measurements Specifications type M-310 Wavelengths(nm) 650±10nm Fiber Model SM,MM Output Power 1mw, 5mw, 10mw, 15mw Spectral Width(nm) ≤5 Emission CW,2Hz can be optional Optical Connector FC/Universal 2.5mm adaptor Power Supply 2pcs AA alkaline batteries Battery Operating Time 30 hours Operating Temperature(℃) -10~+60 Storage Temperature(℃) -25~+70 Dimension (mm) 100*50*25 Weight (g) 50
