| Model NO.: | Miniature bullet camera40988 |
|---|---|
| Packaging Qty: | 1pc/gift box, 100pcs/ctn. |
| Manufacure Name: | Shenzhen beyond tech co.,ltd. |
| Customization: | Available Customized Request |
|---|
Image Device 1/3 Sony CCD Minimum Illumination 0.5 Lux/0.01 Lux/0.001 Lux Built-In Lens f: 3.6mm board lens, weather-proof Number of Pixels PAL:(H)500x(V)582 / NTSC:(H)510x(V)492 Scanning System PAL / NTSC Sync System Internal Synchronization Horizontal Resolution 420TVL/480TVL/520TVL/550TVL/600TVL optional Video Output 1Vp-p 75O Negative White Balance,AGC,BLC Auto S/N Ratio More than 48dB Gamma Characteristic 0.45 Electronic Shutter PAL:1/50~1/100,000s ; NTSC:1/60~1/100,000s Power Consumption 12V+_10%DC,100mA Operation Temperature -10°C~+50°C Storage Temperature -20°C~+60°C Dimension Ø19mm/Ø20mm/Ø22mm optional Accessories Furnished: *DIY cable with BNC/RCA for Video,DC-Jack for Power; *I type bracket; *Manual. Application: outdoor&indoor Connection: refer to FAQ
