| Model NO.: | Wide dynamic range hi-resolution mi66041 |
|---|---|
| Packaging Qty: | 30g |
| Customization: | Available Customized Request |
|---|
Specification Image sensor 1/3 SONY CCD 540TVL,color Effective pixels 768(H)x582(V) Min Illumi. 0.1LUX Lens 3.6mm board lens Menu Yes Dimension 40x40mm Scanning System 2:1 Internal Gamma correction R=0.45 Synchronization Internal Video out signal VBS 1.0p-p.75oms S/N Ratio More than 48dB B.L.C. Adjustable Operating Voltage DC 12V Current consumption 120mA or less White balance Adjustable Gain control Adjustable Electronic Shutter Adjustable A.G.C Adjustable Storage Temp. -20 C - 80 C Operating Temp. -10 C - 60 C Accessory Cable, bracket,manual Weight 30g
