| Model NO.: | Low voltage mini camera38171 |
|---|---|
| Packaging Qty: | 1pc/gift box, 100pcs/ctn. |
| Manufacure Name: | Shenzhen beyond tech co.,ltd. |
| Customization: | Available Customized Request |
|---|
Model AD-125C Image Device 1/3 Sony CCD Number of Pixels PAL:(H)500x(V)582 / NTSC:(H)510x(V)492 Scanning System PAL / NTSC Sync System Internal Synchronization Horizontal Resolution 420TV Lines Video Output 1Vp-p 75O Negative White Balance Auto S/N Ratio More than 48dB Gamma Characteristic 0.45 Minimum Illumination 0.5 Lux Electronic Shutter PAL:1/50~1/100,000s ; NTSC:1/60~1/100,000s Power Consumption 3.3-5V Operation Temperature -10°C~+50°C Storage Temperature -20°C~+60°C Built-In Lens f: 3.6mm board lens Dimension 25x25mm Pinhole lens ,Button lens,optional Accessories Furnished: *DIY cable with BNC/RCA for Video,DC-Jack for Power; *U type bracket; *Manual. Application: indoor Connection: refer to FAQ
