Product Description

Industrial Automation Network Integration Training Equipment DLGK-SIMND Technical parameter 1. Input power: Three-phase five-wire ~ 380V ± 10% 50HZ 2. Leakage protection: I n ≤ 30mA, t ≤ 0.1S 3.380 V three-phase five-wire output power 4.24 V DC power output, 0 ~ 10V analog signal source 5. Accident emergency stop button, power indicator, power indication 6. Off-power misuse power protection 7. AC voltmeter, AC voltmeter to measure 8. DC voltmeter, DC ammeter to measure 9. The working environment: Altitude <4000M 10. Installed capacity: <1kVA 11. Dimension: 1800 * 700 * 1760mm Experiment projects 1. Designing comprehensive training network and systematic experiment projects 2. S7-400PLC programming and communication training 3. S7-300PLC programming and communication training 4. S7-200PLC programming and communication training 5. PC VINCC configuration software basic programming exercises 6. PC remote machine to read and write PLC experiment 7. MPI communications network experiment 8. PROFIBUS communication network experiment 9 Industrial Ethernet using training 10. USS protocol communications network experiment 11. PPI communications network experiment 12. Free port serial communication experiment 13. MM420 inverter basic speed standard transmission, multi-speed control, USS communication speed motor control experiments and experiments 14. Touch screen programming and communications experiments 15. Remote I / O control experiments 16. Control training (may contain PROFIBUS, MPI, RS485 and other network)between the PLC and inverter and PC (WINCC), touch screen and other equipment through the network communication. 17. Master-slave data exchange 18. Automatic, manual control of traffic lights 19. Traffic lights opening and closing time controlled experiment 20. Rolling mill automatic control 21. Three, four elevators automatic control 22. ATC experiment 23. Automatic machining center control experiments 24. Water tower level automatic control 25. Water tower level automatic control with self-diagnosis 3. Factory: Our factory located in Pioneering park overseas Chinese Scholars Jinan city, Shandong Province . We have very strong technical teams with more than 40 engineers and experienced workers. Our products have exported for more than 7 years. 4. We are in a good position to offer series of training set as follows: 1) Electrical technology Know-how Training Set 2) Innovative E-skills&Technology Training Series 3) MCU Technology Training Series 4) Machine Tools Electrical Control Training Series 5) Machine Tools Electrical Control Training Series(Model-type) 6) CNC Machine Tools Maintainance Training Series(Model-type) 7) Building Automatic Training Series 8) PC Training Series 9) Innovative industrial Automatic Control Technology Training Series 10) Pnematic Training Series 11) Hydraulic Training Series 12) Sensor Training Series 13) Motor Training Series 14) Mechatronic Training Series 15) MPS Training Series 16) FMS Training Series 17) Mechanical Training Series 18) Process control series 19) Automotive training series 20) New energy training series 5. Packaging And Delivery Details: Packaging Detail: 1). Packaging for training kit: plastic package + carton + plywood pallets 2). Packaging for training equipment: plastic package + plywood pallet Delivery Detail: 40 to 50 days after Received advanced payment. 6.After-Service And Training for Foreign User 1) For our exported equipments, the Warranty is one year, within one year, if there is any problem for spare parts(except damage by man-made) We can supply and replace free of charge. And if after one year, we also supply the service. The difference is user need to pay it. 2) We dispatch our professional and experienced engineer to install equipments and make training for the end users.
