Product Description

Specifications Basic Hydraulic Trainer Educational Equipment 1, ISO9001, ISO14001, OHSMS18001 DLYY-DH101 Basic Hydraulic Training Equipment 1. Equipment overview DLYY-DH101 type hydraulic training device, is design, research and develop according to experimental teaching outline of the national college "hydraulic transmission" for guidance, and combine with requirements of vocational training and professional further study to the fluid drive. This training device uses operating board of the open structure, all kinds of hydraulic components can be flexible install in operation board, connect with hydraulic pressure tube between components, the quick-change connector of hydraulic hose can make training experiment is fast and safe. Besides large whole set of components can be chose to upgrade! It has very strong expansibility and actual exercise, has the following features: · Can meet the requirements of the school · Meet the base and teaching training system of need of practical applications. · Equipment structure is firm and has good stability · Low noise operation · Layout clear and intriguing design 2. Components specification Hydraulic operation station It consists of aluminum material profile, and can be set up the system according to the different requirements, so it is easy to change the structure. Ambry that be made of special composite material is divided into the upper and lower levels, have their own independent lock system. The every component can be easily to storage. Work station equipped with loop work board and set oil pan to convenient for cleaning equipment. Four caster wheel with crack slot in order to move and install. Due to the point and height isadjustable, convenient for efficient experiment. Panel grooves gap is 25 mm, can easily move all kinds of components inserted on it. Experiment table dimension: 1600(length)× 750(width)× 1700(height) Aluminium panel dimension: 1200(length)× 750(width) Groove gap: 25mm Aluminum wood cabinet: 1 piece Caster with crack groove: 4 pieces 3. Training contents: 1) Directional control circuit 2) Pressure control circuit 3) The flow speed circuit using for throttle valve 4) Speed regulation circuit using for speed regulation valve 5) Sequence action circuit using for sequence valve 6) One-way interlock circuit use hydraulic control one-way valve 7) Locking circuit use o type manual shuttle valve 8) The speed interchange circuit of flow valve short circuit 9) Pressure distance adjustment circuit 10) The other circuit design by themselves 3. Factory: Our factory located in Pioneering park overseas Chinese Scholars Jinan city, Shandong Province. We have very strong technical teams with more than 40 engineers and experienced workers. Our products have exported for more than 7 years. 4. We are in a good position to offer series of training set as follows: 1) Electrical technology Know-how Training Set 2) Innovative E-skills&Technology Training Series 3) MCU Technology Training Series 4) Machine Tools Electrical Control Training Series 5) Machine Tools Electrical Control Training Series(Model-type) 6) CNC Machine Tools Maintainance Training Series(Model-type) 7) Building Automatic Training Series 8) PC Training Series 9) Innovative industrial Automatic Control Technology Training Series 10) Pnematic Training Series 11) Hydraulic Training Series 12) Sensor Training Series 13) Motor Training Series 14) Mechatronic Training Series 15) MPS Training Series 16) FMS Training Series 17) Mechanical Training Series 18) Engrave machine series 5. Packaging And Delivery Details: Packaging Detail: 1). Packaging for training kit: Plastic package + carton + plywood pallets 2). Packaging for training equipment: Plastic package + plywood pallet
