Product Description

Specifications 1. Below 10L/min 2. Rated voltage 380V, rated power 1.5KVA DLQD-DP201 Electro-pneumatic Training Set 1. Equipment overview DLQD-DP201 type electrical pneumatic training device is at the request of modern pneumatic professional teaching experiment, according to "the hydraulic and pneumatic transmission ", "the pneumatic control technology", etc., general teaching material contents design. The system in addition to regular pneumatic basic control circuit experiment, still can be simulate the pneumatic control technology application experiment, pneumatic technology curriculum design, is the typical experiment equipment that the mechanical combine with electrical perfectly. The system adapt in "hydraulic and pneumatic transmission", "pneumatic control technology" which offer by mechanical engineering, mechatronics or automation major in colleges and universities, technical school, vocational school. Also can be used as the comprehensive experimental platform of machine, electricity and pneumatic integration, can reflect comprehensively the most advanced pneumatic technology and machine, light, electricity, the sensor technology which used in manufacturing process of factory mechatronics. Students via the actual operation experiment and the course design can grasp accurately structure of pneumatic components, the control principle of the pneumatic circuit and design method, control principle, etc. Besides, there are large complete sets of components can be chosen to upgrade! They have very strong expansibility and practical working style, and have the following features: · Can meet the requirements of the school · Meet the base and teaching training system of need of practical applications. · Equipment structure is firm and has good stability · Low noise operation · Layout clear and intriguing design 2. Technical parameter Input powersingle phase, three wires, AC 220V, 50Hz/60Hz System pressurebelow 10L/min Motorrated voltage 380V, rated power 1.5KVA Training platform dimension1580mm(L)× 750mm(W)× 1700mm(H) 3. Factory: Our factory located in Pioneering park overseas Chinese Scholars Jinan city, Shandong Province. We have very strong technical teams with more than 40 engineers and experienced workers. Our products have exported for more than 7 years. 4. Product range: 1) Electrical technology Know-how Training Set 2) Innovative E-skills &Technology Training Series 3) MCU Technology Training Series 4) Machine Tools Electrical Control Training Series 5) Machine Tools Electrical Control Training Series(Model-type) 6) CNC Machine Tools Maintainance Training Series(Model-type) 7) Building Automatic Training Series 8) PC Training Series 9) Innovative industrial Automatic Control Technology Training Series 10) Pneumatic Training Series 11) Hydraulic Training Series 12) Sensor Training Series 13) Motor Training Series 14) Mechatronic Training Series 15) MPS Training Series 16) FMS Training Series 17) Mechanical Training Series 5. Packaging And Delivery Details: Packaging Detail: 1). Packaging for training kit: Plastic package + carton + plywood pallets 2). Packaging for training equipment: Plastic package + plywood pallet Delivery Detail: 40 to 50 days after Received advanced payment. 6. After-Service And Training for Foreign User 1) For our exported equipments, the Warranty is one year, within one year, if there is any problem for spare parts(except damage by man-made) We can supply and replace free of charge. And if after one year, we also supply the service. The difference is user need to pay it. 2) We dispatch our professional and experienced engineer to install equipments and make training for the end users.
