Product Description
Machine: TW7007 Roof Tile Roll Forming Machine,Roof Sheet Roll Forming Machine,Roof Panel Roll Forming Machine,Roofing Sheet ROll Forming Machine
A) Technical Data
1. Decoiler: Manual Decoiler
2. Weight Capacity Of Decoiler: 5 Ton
3. Main Motor Power: 5.5 Kw
4. Hydraulic Motor Power: 2.2 Kw
5. Roll Stand: 13
6. Raw Material Width: 1000mm, 1200mm ( or according to customers requested )
7. Thickness Of Raw Material: 0.2-0.8 mm
8. Necessary Covered Width: 820, 1025mm ( or according to customers requested )
9. Machine Frame stand: Welded structural steel
10.Thickmess of Fame Steel: 16mm
11. Type of forming machine: Single station with chain transmission
12. Material of Roller: High grade 45# forge steel, Polished and coated with 0.05mm Chrome Surface.
13. Transporting Type: Chain Transmission
14. Material Of Chain: High Grade 45#, Heated and quenched HRC 45-50
15. Main Axis Material: High grade 45#
16. Axis Diameter: 70mm
17. Working Speed: 10-15 m/min
18. Voltage: 380V, 3 Phase 50Hz ( or according to customers local requirement )
Company Profile
| |
Business Type: |
Wuxi Techwell Roll Forming Machine Co.,Ltd mainly produce Roll Forming Machine, Sandwich Panel Machine, Roof tile machine, wall panel machine, C/Z Purlin machine, floor deck machine, guardrail machine,downpipe machine, channel machine, gutter machine... |
| |
Comapany: |
Wuxi techwell roll forming machine co.,ltd |
| |
Year of Establishment: |
2000 |
| |
Address: |
No. 16,JIngshi Rd |
| |
City: |
Wuxi |
| |
Zip/Postal: |
214046 |
| |
State: |
Jiangsu |
| |
Country: |
China |
Wuxi Techwell Machinery Manufacturing Co.,Ltd is engaged in the produce, design, adjustment and installation all kinds of Cold Roll Forming Machine, Sandwich Panel Machine and Slitting & Cut to length Line in China. And we can produce portable gutter / downpipe machines, at present, in China, only our factory can produce portable machines.
Our Main Machine:
roll forming machine,roof tile forming machine,C/Z/U/W purlin forming machine, floor deck forming machine,guardrail forming machine,k span forming machine,gutter forming machine,downpipe forming machine,channel forming machine,double layer forming machine,door frame forming machine,sandwich panel machine, corrugated sheet forming machine,glazed tile forming machine,trapezoidal sheet forming machine,box beam forming machine,ibr sheet forming machine,bemo sheet forming machine,eps sandwich panel machine,pu sandwich panel machine, ridge cap forming machine,slitting machine,cut to length machine,roof curving machine,hydraulic decoiler,embossing machine…
--------------------------------------------------------------------------------------
