| Model NO.: | Copy router for door&window17663 |
|---|---|
| Packaging Qty: | Wood box |
| Min. Order (MOQ): | 1 |
| Manufacure Name: | Shunde kingtool |
| Customization: | Available Customized Request |
|---|
The machine adopts the half-automatic control copy operation, with extra big process size and high accuracy. It is fit for the through-hole copy machining of different size of aluminum alloy curtain wall and window profiles and cleanness appliance profiles. Utilizes the mold and copy the shape of the hole to the workpiece as per 1:1 ratio. MAIN TECHNIQUE PARAMETER 1.Worktable size (L*W)........................980*320mm 2.Max. distance of milling head from left to right.........500mm 3.Max. distance of milling head from front to rear.........220mm 4.Max. space height of milling head...........200mm 5.Milling cutter diameter in common...........D8mm optional...............D3~D5mm 6.Milling cutter rotation speed...............12000r/min 7.Motor power.................................N=1.1KW 8.Motor rotation speed........................2830r/min 9.Cylinder feeding travel.....................50mm 10.Working air pressure.......................0.6~0.8Mpa 11.Overall dimension (L*W*H)..................1080(2880)*950*1500mm 12.Weight.....................................500KG
