Product Description

1. Stylish, delicate and elegant appearance 2. Very silent printing thru direct thermal printing method 3. Paper end sensors and self-motion memory printing function 4. Support 3.3V low voltage system 5. Add coordinate curve printing function 6. Serial (RS-232C, TTL), 485 interface/Parallel interface& 7. Abundant figure/curves/characters print function 8. Easier paper loading Item Specification Printing method Direct thermal line printing Paper out detection Paper end sensors function paper loading way Easy paper loading Paper width 57 mm Print width 48 mm resolution ration 8 dots/mm(384 dots/line) life of printing head 6×106 character lines Printing speed 60mm/sec (when the character ratio is 25%) Character 6x8dots , 8x16dots,or12x24dots Chinese character library GB2312,16x16dots,or24x24dots outline dimension(WxHxD mm) 85mmx85mmx55.5mm Installation dimension(WxH mm) 80mmx80mm Paper supplied Thermal roll paper (57mm wide, 50mmø) Interface Serial(RS-232C ,TTL)/Parallel interface Input Power DC 5V, 15W Operating temperature 5°C ~ 50°C Storage temperature -20°C ~ 60°C Operating humidity 10°C ~ 80°C Storage humidity 10°C ~ 90°C
