Product Description

1. Direct thermal line printing 2. Stylish, delicate and elegant appearance 3. Serial (RS-232C,TTL ) interface/Parallel interface/USB 4. Abundant figure/curves/characters print function Item Specification Printing method Direct thermal line printing Paper width 57 mm Print width 48 mm resolution ration 8 dots/mm (384 dots/line) Life of Print Head 6,000,000 character lines Character per Line 64/32/24 Printing speed 40mm/sec(when utilization rate is 25%) Character size 6x8 dots,8x16dots or 12x24dots Chinese character library GB2312, 16x16dots, or 24x24dots outline dimension(W x H x D mm) 110mmx64mmx50.7mm Installation dimension(W x H mm) 102.4mmx56.4mm Inlaid deepness 48.2mm Paper supplied Thermal roll paper (57mm wide, 33mmø) Interface Serial(RS-232C,TTL)/Parallel Interface/USB Input Power DC 4.2V-7.5V,15W/DC9-24V,15W Operating temperature 5°C ~ 50°C Storage temperature -20°C ~ 60°C Operating humidity 10% ~ 80% Storage humidity 10% ~ 90%
