Product Description

1. Direct thermal line printing 2. Stylish, delicate and elegant appearance 3. Serial (RS-232C,TTL ) interface/Parallel interface 4. Copy function of LCD screen 5. Abundant figure/curves/characters print function Item Specification Printing method Direct thermal line printing Paper width 57 mm Print width 48 mm resolution ration 8 dots/mm (384 dots/line) Character per Line 64/32/24 Printing speed 30mm/sec(when utilization rate is 25%) Character size 6x8 dots,8x16dots or 12x24dots Chinese character library GB2312, 16x16dots, or 24x24dots outline dimension(W x H x D mm) 111.8mmx65.8mmx66mm Installation dimension(W x H mm) 103mmx57mm Inlaid deepness 60.8mm Paper supplied Thermal roll paper (57mm wide, 30mmø) Interface Serial(RS-232C,TTL)/Parallel Interface Input Power DC 5V ,3A,Max 4A Operating temperature 5°C ~ 50°C Storage temperature -20°C ~ 60°C Operating humidity 10% ~ 80% Storage humidity 10% ~ 90%
