Product Description

9mm high-speed corrugated paperboard belt, corrugated paperboard belt, corrugated belt, paperboard belt, Huatao Wire Belt Factory Tel: 86-311-80772027 Fax: 86-311-80690567 Skype: huatao04 E-mail:troy.l@huataogroup.com Huataogroup11@outlook.com Sale09@huataogroup.net Huatao Woven high speed corrugator belt was developed to transfer board and the rapid drying of the board. The structure and the quality fabric of the belt facilitate steam evaporation from the board. The belt is 3-layer belt. The structure of two surface layers is not the same as the middle layer. This structure is developed to produce flat boards on high-speed corrugating machines. The surface of the belt is twill, this reduces the noise while the belt running on the machines. The material of the two surface layers are not the same as the middle, this can increase the friction coefficient. Product Features: 1. Straight cut edge and long service life. 2. Level surface, clean mark. 3. Hot-press and flocking joint. 4. High moisture absorption and release; Low noise and high speed of operation. Specification: Product Model: high speed corrugator belt Thickness: (9 ± 0.3）mm Width: 1400 - 2800 mm Heat-resistance: 200℃ - 245℃ Tensile strength: 65Mpa Coefficient of friction: ≥0.4 - 0.45µ Weight per unit: (7±0.3) kg/m2 Air-permeability: 300-400 m³ / m2h (1kpa) Run Speed: ≥ 200 m/min
