Product Description

MECHANISM TECHICAL DESCRIPTION 01 Channel Single channel 02 Pulse Amplitude Adjustable, 0-80mA, Max output 80mA (peak to peak) into 500ohm load. 03 Output Voltage Adjustable, 0-40V, Max output 40V (peak to peak) into 500ohm load. 04 Wave Form Asymmetrical Rectangular Biphasic Pulse. 05 Power Supply Two AA Batteries 06 Size 9.2cm(L) x 6.2cm(W) x 2.85cm(H) 07 Weight 123 grams (2 batteries included) 08 Pulse Rate Pre-setting, 1~100 Hz 09 Pulse Width Pre-setting, 150 μs, 200 μs or 250 μs 10 Programme A, B, C, D, E, five pre-set programme of options. 11 Programme A ,B, C, E The programme details of A, B, C, E are as follows. Parameters are preset at fixed values. The 2 seconds ramp time includes 1 second ramp up, and 1 second ramp down. Each programme is repeated in a constant cyclic pattern. Programme Rate Width Contraction Relaxation Ramp Cycle (Hz) (μs) (Sec.) (Sec.) (Sec.) (Sec.) A 35 250 4 8 2 14 B 40 200 6 15 2 23 C 10 250 5 3 2 10 E 20 250 5 5 2 12 1
