Product Description
Hydraulic slewing crane &rescue boat liferaft landing device
This equipment uses hydraulic drive rotary type,by its own gravity of the boat to make it down to the water,which could make the boat slew to outboard in case of losing of the power supply.While lowering,the sailors in the boat could pull the remote ontrol steel rope,through the pulley around the reel.To lift the winch hammer to control the boat/raft lowering or stop.This also could be operated by sailors on the operation deck.The winch is use of motor-driven winch gear box and gear box with centrifugal speed and manual brake function delegated.The device is designed and manufacturing according to the latest SOLAS standards and international standards.
type Max.Working load Hoisting load Hoisting speed Landing speed Rope capacity of the reel Max rotation radius
HD2-10 21KN 14KN
≥18m/min 40-60m/min 30m 4500mm
HD3-10 30KN 27KN 4500mm
HD3-10-1 23KN 14KN 7000mm
HD3-10-2 23KN 18KN 7000mm
Crane main technical data
Max.hoisting load Rope capacity of the reel Maximum rotation angle Landing speed Rotation radius
2T
30M
≤330°
≥15m/min
10000MM
3T
3T
3T
&&&& 275N CE approval inflatable life jacket
CO2 fire extinguishing system
Marine horizontal/vertical oil fired boiler
Marine air compressor
marine centrifugal pump
marine hydraulic steering gear
Hydraulic capstan
Tunnel thruster/bow thruster
Company Profile
| |
Business Type: |
Marine water treatment plant, marine life saving equipment, marine fire fighting equipment, marine mooring equipment, bow thruster, FIFI system |
| |
Comapany: |
China deyuan marine fitting co.,ltd |
| |
Year of Establishment: |
2010 |
| |
Address: |
No9-8 Xintai building,Shapingba District |
| |
City: |
Chongqing |
| |
Zip/Postal: |
400060 |
| |
State: |
Chongqing |
| |
Country: |
China |
CHINA DEYUAN MARINE FITTING COMPANY LIMITED is one of the leading and trusted supplier of marine equipment and offshore equipment in China.
We do export business globally in the market for many years and have our owned shareholding factory,also establish good business relationship with other factories with high quality products,competitive price.
Our products include:
Marine life saving equipment: (immersion suit,life boat,inflatable boat,life raft,life jacket,life jacket light etc)
Marine fire fighting equipment:(FIFI system,SCBA,EEBD,fire suit,heat insulation suit,fire extinguisher etc)
Environment Protection Equipment:(Oily water separator,sewage treatment plant,fresh water generator,UV-sterilizer etc)
Marine Mooring Equipment:(marine anchor,anchor chain etc)
Marine Power&Propulsion Equipment:(Tunnel thruster,marine propeller,marine shaft etc)
Marine Deck Equipment:(Marine Windlass,Marine Winch,Marine Davit)
Marine Diesel engine:(CUMMINS Diesel engine,Weichai diesel engine,Deutz diesel engine)
These products are SOLAS compliant, approved by different Classification Society,such as ABS,BV,KRNK,GL,LR,RINA,CCS,DNV,IRS
Our product has been sold to all over the world with good quality and competitive price.And we always insist on doing everything sincerely and seriously.Hope to have the great honor to be yr partner forever.
.
