Product Description

Washing Machine for Rail Transit BEIJINGTEPO-AUTO WASHING 1 General scheme 1.1 General summarize Automatic Train Washing Machine adopts to clean the dust,oil stain and other besmirch of the train. By using the water, cleaning agent and the brush to wash two lateral of the railroad train, include the car door with the pane. The Automatic Train Washing Machine is constituted by washing system, electricity control system, water supply system, compressed air supply systems. It adopts the train self-draught. The train passes the warehouse to wash and brush with the speed of 2-4 km/ h. Automatically proceeds railroad train two lateral washing. Wash the bodywork surface to have no the dust, mud with the other attachment. Wash the empress's water to pass by to handle to behind circularly use. Have the auto or manual control function and can choose if use a cleaning agent. 1.2 This washing machine has the following functions: 1) This washing machine can auto wash the lateral extern surface. 2) This washing machine can auto wash the coping of the train. 3) This washing machine provides to automatically clean the train, meanwhile, manual cleaning is also possible. 4) Each working section can work manually and move from point to point. 5) This machine provides to display the washing state of each working section, any failures and relevant parameter. 6) This machine have the perfect system protecting function. It also provides to give alarm both automatically and manually in the event of a failure. 7) This machine provides two alternative ways of washing: detergent solution washing and fresh water washing. 8) This machine provides two alternative ways of drain or watering: auto and manual. 9) This machine provides the function: reuse the circulating water. 10) This machine provides the record function: the trains number, washing times, if using the detergent or not. 1.3 Working mode The mode of the automatic train washing machine is “go washing mode”. The lateral and coping of the train is washed when the train is going with the limited speed. The train moves by its own power. The driver drive the train with the limit speed of 2-4km/h. 1.4 Constituting of equipment Automatic Train Washing Machine consists of pre-cooling and pre-wetting station, front .lateral detergent brushing washing station, roof detergent brushing station, lateral initial water brushing station, water supplying station, the compressed air supplying station, water circulating and disposing station, detergent supplying station, electric appliances and control system. All of the components tally with the international standard IEC, ISO, The Chinese national standard GB and Railway Ministry of China standard TB are also adopted. 1.5 Work conditions for the equipment 1) Main technical parameter of Metro vehicle which is washed. The device is matched with the train which is used. These parameter is treated to settle. 2) Envir
