Product Description

Product Description: Micro Vickers Hardness Tester SMV-1000, is precision hardness testing machines integrate the technology of optics, mechanics and computer. It is applicable to measure the hardness value of ferrous metals, non-ferrous metals, IC thin sections, coatings, ply-metals; Glass, ceramics, agate, precious stones, and it can be tested about the depth and the trapezium of the carbonized layers and quench hardened layers. Technical Specifications : Model SMV-1000 Testing Forces (0.098, 0.246, 0.49, 0.98, 1.96, 2.94, 4.90, 9.80) N (10, 25, 50, 100, 200, 300, 500, 1000) gf Turret manual Testing forces loading switch Automatic ( loading / dwell / unloading ) Magnification of the Microscope 200×, 400 × Dwell Time of the Test Force (5-60)s Min. resolution of the Testing Drum Wheel 0.0625um Testing range 1HV—2967HV Dimension of the XY stage 100 × 100 mm Travel of the XY stage 25 × 25mm Max. height of the specimen 70 mm Instrument throat 95mm Light source Halogen light source Accuracy Standard conforms to EN-ISO 6507 Power Supply 110V/220V,60/50Hz Dimension & Net Weight 425 × 245 × 490 mm & 30Kg Standard delivery XY stage ; Thin specimen anvil ; Fork-shaped anvil ; Fine wire anvil; Level; Adjustable screw ; 10 ×eyepiece ; 20x and 40x objective; Micro Vickers hardness blocks (high and medium) Optional accessories: Knoop indenter Mini-printer CCD adapter, Camera and Monitor Micro hardness testing software Auto-turret
