Product Description

Automatic stationery shrinkable packaging machine Jinan Dongtai has been known for its product quality, our automatic packaging machine is to obtain the approval of many customers, the Dongtai automatic packaging machine customers encouraged better improve automatic packaging customers because Dongtaimachine to achieve a more effective growth.xj21dtjx Our company products include: Filling Machine,Packaging Machine,Packing Machine,ect. Applicability: Single and group products of medicine, food, drinking, stationery, printings, cosmetic, electronic porducts, toys, auto parts, etc Specifications BS-400LB - Sealing type: L-sealing by means of L-bar - Power supply: 380V/50-60Hz/3phase - Packing capacity: 35 packs per minute (depends on product size and film width) - L-bar size: 570x480 mm - Max height of sealing frame: 125 mm - Film type: center-folded film with 12-80 micron - Max film size: width: 520mm (folded), outer diameter: 400mm - Conveyor speed: 19 m/min - Working height: 780-850 mm - Rated power consumption: 1.25 kW - Air pressure: <=0.5MPa (5 bar) - PLC: SIEMENS CPU - Sealing system: permanently heated seal bar with easy-exchangeable sealing blade with Teflon, temperature controlled and detected by PLC - Operating interface: Touchscreen Eview MV506, display operation guidance and error diagnostic - Machine material: stainless steel - Machine dimension: 1600x770x1450mm BMD-450B - Power supply: 380V/50-60Hz/3phase - Oven size: 1200(length) x 450(width) x 220(height) mm - Conveyor speed: variable, 40 m/min - Conveyor: chains with rotating silicon coated rods - Temperature control: By electronic thermostat - Rated power consumption: max 7 kW - Working height: 780-850 mm - Machine material: stainless steel - Machine dimension: 1600x600x1260mm Related products links: Liquid filling machines | filling machines | Fillers | Filling Equipment | Inline Filling Systems
