Product Description

Detail Description Image Sensor: 1/3"SONY CCD Resolution: 420/480/520TVL Option Total Pixels (HxV): NTSC : 510(H) x 492(V) PAL : 500(H) x 582(V) / NTSC : 768(H) x 494(V) PAL : 752(H) x 582(V) Option Scanning Frequency: NTSC : 15.734 KHz(H), 59.94 Hz(V) PAL : 15.625 KHz(H), 50 Hz(V) Scanning System: 2:1 Interlace S/N Ratio: More than 48/52dB (AGC Off) Option Min. Illumination: 0.003/0.5/0.8 LUX Option Sync.System: Synchronization Electronic Shutter: NTSC : 1/60 sec / PAL : 1/50 sec Gamma: ? = 0.45 Video Output: 1.0 Vp-p Composite (75?) AGC: Auto IR LED: 12 unit 850mm up to 5~8meter IR LED Operation: On (1 Lux) / Off (3 Lux) Power: DC12V (±10%), Max. 250mA Cable: BNC/DC JACK Operation Temp: -10?~+50? RH95% Max Storage Tempe: -20?~+60? RH95% Max Lens: 3.6mm Board Lens Color: Black
