Product Description
Polypropylene Tellerette 2K,Tellerette 2k,Tellerette 2R Tower Packing maintains good liquid distribution through packing depths in excess of 10 metres. Good initial liquid distribution is essential. Spray headers using full cone spray nozzles are recommended. Weir distributors are not recommended.B. Design of the packing supports is important.
we can make Tellerette 2K in Polypropylene, PVDF, PVC etc.
Specifications for Tellerettes.
MODEL Outer Diameter (mm) Height surface area (m2/m3) Void volume 3/m3 Dry packing factor ( m-1 )
O 25 9 269 82 488
1R 47 19 185 88 271
S 51 19 180 89 255
M 73 28 127 89 180
L 95 37 94 90 129
LL 145 48 65 95 76
2K 83.00 32 98 92 16
3K 105.00 56 72 96 9
Tellerette tower packing is a type of inert packing with the appearance of a circular-wound spiral, used to create a large surface area to increase contact between falling liquid and rising vapor; used in gas-absorption operations
Tellerette 2K || Tellerette 2R ||
