| Model NO.: | 39 |
|---|
| Customization: | Available Customized Request |
|---|
Automatic stationery shrinkable packaging machine The packaging machines of Jinan Dongtai can reduce dust, reduce labor intensity, and raise labor efficiency.xjdt2013FM Our company products include:Oil filling machine,Liquid filling machine,Paste filling machine,ect. Applicability: Single and group products of medicine, food, drinking, stationery, printings, cosmetic, electronic porducts, toys, auto parts, etc Specifications BS-400LB - Sealing type: L-sealing by means of L-bar - Power supply: 380V/50-60Hz/3phase - Packing capacity: 35 packs per minute (depends on product size and film width) - L-bar size: 570x480 mm - Max height of sealing frame: 125 mm - Film type: center-folded film with 12-80 micron - Max film size: width: 520mm (folded), outer diameter: 400mm - Conveyor speed: 19 m/min - Working height: 780-850 mm - Rated power consumption: 1.25 kW - Air pressure: <=0.5MPa (5 bar) - PLC: SIEMENS CPU - Sealing system: permanently heated seal bar with easy-exchangeable sealing blade with Teflon, temperature controlled and detected by PLC - Operating interface: Touchscreen Eview MV506, display operation guidance and error diagnostic - Machine material: stainless steel - Machine dimension: 1600x770x1450mm BMD-450B - Power supply: 380V/50-60Hz/3phase - Oven size: 1200(length) x 450(width) x 220(height) mm - Conveyor speed: variable, 40 m/min - Conveyor: chains with rotating silicon coated rods - Temperature control: By electronic thermostat - Rated power consumption: max 7 kW - Working height: 780-850 mm - Machine material: stainless steel - Machine dimension: 1600x600x1260mm Related products links: Liquid filling machines | filling machines | Fillers | Filling Equipment | Inline Filling Systems ------------------------------------------------ JiNan XunJie Packaging Machinery Co., Ltd Department: International Trade Department Post Code/ZIP: 250100 Contact Person: karen Gong(sales manager) Tel: 0086-0531-88738866-605 Fax: 0086-0531-88902662 Mobile Phone : 86-15866784676 MSN: dongtaipack@hotmail.com Email: shandongxunjie@163.com Website: http://www.dongtaipack.com/ <-> filling machines http://www.ltete.com/ <-> Fillers http://www.xunjiejx.com/ <-> Filling Equipment http://www.jinanxunjie.cn/ <-> Inline Filling Systems Address: No.3843,Jichang Road,Lingang Development Zone,Jinan China
