Product Description

Manufacturer Supply all type of high voltage ceramic capacitors (high voltage MLCC), Such As: 0805: 1PF~ 103(500V), 104(250V); 1206: 1PF~103(2000V), 104(500V), 154~474(250V); 1210: 1PF~102(4000V), 102~103(3000V), 104~224(500V), 224~474(250V), 105(100V); 1812(1808): 1PF~103(4000V), 153~273(3000V), 33nF (2000V), 68nF (1000V), 100nF 500V/630V, 0.15uF 100v/250, 0.22uF 100V/250v, 0.33uF 100v/250v, 0.47uf 100v/250v, 1uF 100v/250v, 2.2uF 100v 2225(2220):1PF~103(4000V), 153~223(3000V), 333~473(2000V), 0.1uF 500v/630v/1000v, 0.15uF 100v/250V, 0.22uF100V/250V, 0.33uF100v/250V, 0.47uf100V/250V, 1uF 100V/250V, 2.2uF 100V Applications: General digital circuit, Power supply bypass capacitors, Liquid crystal modules, Liquid crystal drive voltage lines, LSI, IC, converters (both for input and output), Smoothing capacitors, DC-DC converters (for both input and output), Switching power supplies (secondary side) Rated Voltage: 6.3V, 10V, 16V, 25V, 50V, 100V, 200V, 500V, 1000V, 2000V, 3000V, 4000V Capacitance: 0.47pf~100pf (101)/4000V, 120pf, 150pf, 180pf, 220pf (221)/3000V, 270pf (271)/3000V, 330pf (331), 390pf, 470pf (471)/3000V, 560pf, 680pf (681)2000V, 820pf, 1000pf (102), 1200pf, 1500pf, 1800pf, 2200pf (222), 2700pf (272), 3300pf (332), 3900pf (392), 4700pf (472), 5600pf (562), 6800pf (682), 8200pf, 10nf(103)/500V, 12nf/1000V, 15nf / 2000V /3000V, 18nf/2000V, 22nf (223)/500V/1000V, 27nf (273)500V, 33nf(333)/500V/1000V, 39nf/250V500V, 47nf (473)/500V/630v, 100nf (104) / 500V/630V/1000V, 124, 154, 184, 220nf (224)500V/1000V, 270nf (274), 0.33uf (334), 394, 470nf (474), 560nf (564), 680nf (684), 824, 1uf (105)100V/250V, 1.2uf (125), 2.2uf (225)50V/100V/250V, 2.7uf (275)/50V/100V, 3.3uf (335)/25V/50V/100V, 4.7uf (475)16V/25V/50V, 5.6uf (565)/16V/25V/50V, 6.8uf (685) /16V /25V /50V, 10uf (106), 22uf (226)/16V/25V/50V Characteristics: Operating Temperature Range: -55C to 125C Rated Voltage (V): 6.3V – 4000VDC Capacitance Range: 0.47pF – 22uF Temperature characteristic: NPO (COG), X7R, X5R, Y5V, Z5U Case Size: 0201 (0603), 0402 (1005), 0603 (1608), 0805(2012), 1206 (3216), 1210 (3225), 1808 (5420), 1812 (4532), 2220 (5750), 2225 (5760)
