| Model NO.: | Hsz chain hoist29813 |
|---|
| Customization: | Available Customized Request |
|---|
Model HSZ-1 HSZ-1.5 HSZ-2 HSZ-3 HSZ-5 HSZ-10 Capacity 1T 1.5T 2T 3T 5T 10T Standard lifting height 2.5M 2.5M 2.5M 3M 3M 3M Test load 1.5T 2.25T 3T 4.5T 7.5T 12.5T Chainpull to lift full load 309N 343N 314N 343N 383N 392N No.of load chain fall lines 1 1 2 2 2 4 Diameter of load chain 6mm 8mm 6mm 8mm 10mm 10mm Net weight 10kgs 16 kgs 14 kgs 24 kgs 36 kgs 68 kgs Gross weight 13 kgs 20 kgs 17 kgs 28 kgs 45 kgs 83 kgs Packing masurement (L*W*H ) cm 30*24*18 34*29*20 33*25*19 38*30*20 45*35*24 62*50*28 Extra weight meter of extra lift 1.7kgs 2.3 kgs 2.5 kgs 3.7 kgs 5.3 kgs 9.7 kgs
