Product Description

OIL EXPELLER / OIL SCREW PRESS MODEL :VK-200 FEATURES : vk200GearBox : Double reduction Gear box Kettle / Cooker : Multi stage cooker for the conditioning of seeds Chamber :Vertical Hinged and can very easily be opened for replacement of worms or cage bars. This saves a lot of time and labour. Steel Fabricated Chamber: Reduces time and labour for relining of Cage Bars. Bearings : Heavy duty Ball and Roller bearings are fitted for maximum life and low noise operation. Compressing : Crammer Shaft gives extra Cramming of the seed or cake in the Feed Shaft Withdrawal : The main Worm Shaft can be withdrawn very easily without disturbing the gear section in any way. Pressing worms and collars can be changed without disturbing the main shaft. The thrust of the pressure worms is taken upon large spherical roller thrust bearings. Easy to install, high yield at low operating cost, capable of extracting oil from all known oil seeds. Reduced internal wear and tear Best Quality of Oil & Cake. Maintenance is less & easy Hardened Worm Assembly Cast Iron Bodies: For perfect alignment and stability. Steel Fabricated Base Model of Expeller SHREEJI VK-200 Chamber Fabricated chamber HP 3 Phase 50 HP Motor Capacity 20 TON / 24 Hour
