Product Description

CEILING MOUNT DENTAL MICROSCOPE Technical Specifications: BINOCULARS:- Binocular Tubes : Fixed INCLINED at 45 degree MAGNIFICATION SYSTEM:- Magnifications : 3 Step [ 5x, 10x & 20x ] EYE PIECES Eye Pieces : 10x W.F. MAGNIFICATION RANGES:- Objective Lens : F=200mm Field of View : 50mm IPD Adjustment : 55mm to 75mm FOCUSING:- Fine Focusing : Manual Fine Focusing by Knob ILLUMINATION:- Illumination : 15V/150W twin Halogen Lamps with 100% coaxial through the lenses focused Fiber optics light guide 1.5 meter, bright light more than 80,000 Lux, maximum at standard condition Field of Illumination : 70mm Arm : Counter balanced pantographic arm with 320 degree rotation. Vertical Range of Counter Balanced Arm : 250mm to 300mm Mounting Type : Ceiling Mounted. Ceiling Plate with But & Bolts shall be provided. Weight : 22kg (Approx.) Power : AC 220V, 50/60Hz. (110V on request), : Muti-plug-Adapter shall be provided
